| Weight |
0.3 kg |
| Dimensions |
10 × 7 × 7 cm |
Size and Weight
- Size ( without mount ):
- 89.4mm x 58mm x 58mm
- Size ( with mount ):
- 142mm x 58mm x 58mm
- Weight ( without mount ): 146g
- Weight ( with mount ): 175g

Camera
- Max video resolution: 1080p/30 fps, MJPEG, H264
- Supported resolutions: 1920×1080, 1280×720, 960×540, 640×360
- Supported frame rate:
- MJPEG: 1920×1080@[30 24 20 15], 1280×720@[60 30 24 20 15],
- 960×540@[60 30 24 20 15], 640×360@[60 30 24 20 15]
- YUV: 1920×1080@5, 1280×720@[10 5], 960×540@[15 10 5],
- 640×360@[30 24 20 15 10 5]
- H264: 1920×1080@[30 24 20 15], 1280×720@[60 30 24 20 15]
- 960×540@[60 30 24 20 15], 640×360@[60 30 24 20 15]
- Digital zoom: 2x
- Field of view: 90°
- Built-in Audio: Built-in dual omni-directional mics with noise cancellation
2-Axis Gimbal
- Gimbal installation: Non-removable
- Controllable range: Pan: ±150°,Tilt: ±45°
- Structurally possible range: Pan: ±160°;Tilt: ±90°
- Max control speed: 120°/s
Outer Charging Port & Contact Interface
- Lens
- Camera Indicator
- Microphone
- DC Power Port
- USB Type-C Port
- UNC 1/4-20
- Magnetic Base
System Requirements
- Windows® 10 or later, Windows 8, Windows 7
- macOS® 10.13 or later
Software:Â OBSBOT TinyCam
Operating Environment: Camera working environment temperature: 0°C-40°C
Package Content
- OBSBOT Tiny AI Webcam X1
- Type-C data power cable X1
- Magnetic mount X1
- User Manual X1
- Warranty card X1
